卡口监控杆



杆件类产品：
包括监控杆、八棱杆、标志杆、龙门架、限高杆、智慧杆、太阳能灯杆，高灯杆、景区杆、河道杆、山顶杆等支持加工定制，广泛应用于城市管理、交通、能源、景观、特殊环境等多个领域。


产品特点与优势：
一、卡口监控杆：
监控杆安防监控系统中的核心支撑设备，其设计结合了结构强度、功能性和环境适应性等多重优势。以下是其核心产品优点及特点的详细分析：

结构设计与强度优势

1、外形结构：八棱锥形+圆形+方形等多种外形结构

1.11八边形锥形设计（上口径小、下口径大），相比传统圆形或方形杆，提供更大的支撑面积和侧向刚度，抗风能力达12级以上（36.9米/秒），抗震等级达8级，确保极端天气下的稳定性。
1.12圆形监控杆：若项目需快速部署、临时使用，或对安全碰撞、轻量化有高要求（如停车场闸杆、活动安防）。

1.13选方形/八角监控杆：若追求超长寿命（20年+）、高承载扩展性及抗极端天气能力（如高速卡口、智慧城市主干道）。

1.14兼顾场景：沿海地区优先八角杆防腐抗风；小区景区可选圆杆或定制仿古方杆提升美观度。

1.15实际选择需结合预算、设备负载及维护周期—供两类杆型的深度定制服务，适配复杂需求。

2、高强度材质

主杆选用Q235低碳钢（壁厚≥4mm，底法兰≥14mm），无缝钢管工艺增强抗压能力；横臂采用碳钢管（壁厚3~5mm），兼顾轻量化与承重需求。

精密制造工艺

焊接技术：自动埋弧焊接，焊缝无漏焊、气孔，通过超声波探伤检验（符合GB/T3323-1987标准）。垂直度控制：安装后垂直度偏差≤1.0%，保障设备拍摄角度精准。

二、防腐与耐用性

2.多重表面处理

2.1热镀锌层：锌层厚度≥86μm（国标GB/T13912-2002），经酸洗、钝化等工序，防腐寿命超30年。

2.2静电喷塑：表面覆盖≥100μm塑层（进口塑粉），附着力达GB9286-88 0级，耐候性强，可选配色适应环境。

2.3密封防渗设计

杆体顶端密封防水，过线口优化处理避免割伤线缆，箱体配备防水舱门，防护等级达IP65。

三、功能与安全性

3集成化设备箱

3.1箱体设多向敲落孔，支持上下左右进线；内部配置防雷接地装置、漏电/短路保护电路，符合电气安全标准（额定电压AC220V/380V）。

3.2箱门通过编织软线连接PE点，形成连续保护电路，防止触电风险。

3.3灵活扩展性：可同时搭载摄像头、信号灯、气象传感器、LED屏等多种设备，适用于智慧交通、安防监控、环境监测等场景。

3.4便捷维护设计：检修舱门采用落栓开启式，维护时无需专用工具；预埋件分体式结构（法兰盘螺栓连接），简化运输与安装。

四、应用场景与适应性

4.1多环境适用：恶劣气候：海滨、高湿度地区可选复合材料款（如玻璃纤维杆），抗盐雾腐蚀。

4.2复杂地形：预埋基础采用C25混凝土浇筑，地笼结构增强抗拔力，适应沙土、坡地等不稳定地基。

4.3广泛覆盖领域：包括城市道路监控、高速卡口、治安卡点、水利监测、机场港口，隧道、桥梁、收费站等，杆高支持6~12米定制，臂长可达12米。

4.4用途： 安装摄像头抓拍违章、监测车流、事故取证等。



总结：

八棱监控杆通过八棱锥形结构+Q235高强度钢提升抗风抗震能力，以热镀锌+静电喷塑实现超长防腐寿命，并借助模块化箱体、防雷接地、智能扩展接口满足多功能集成与安全运维需求。其设计兼顾稳定性、耐久性及环境适配性，成为现代智慧城市安防系统的核心基础设施之一。



五．产品形状、材质与定制规格
5.1产品形状：圆形/方形/六角/八角/交通信号/八角监控杆

5.2产品材质：Q235碳钢/铝质/201不锈钢/304不锈钢
5.3可定制规格：

常规高度或长度：1米/2米/3米/4米/5米/6米/6.5米/7米/8米/9米/10米/12米/15米/18米/20米/30米等

常规口径：30mm/40mm/50mm/60mm/80mm/120mm/140mm/160mm/180mm/200mm/220mm/240mm/260mm/280mm/300mm/320mm/350mm/400mm/450mm/500mm/800mm/1000mm等

常规厚度：1.0mm/1.2mm/1.5mm/2.5mm/3.0mm/4.0mm/5.0mm/6.0mm/8.0mm/10mm/12mm/14mm/16mm等

根据需方要求产品价格：60元-60万元/套（含热镀锌喷塑，承重标准）。





Rod products

Our products include surveillance poles, octagonal poles, sign poles, gantry frames, height limit poles, smart poles, solar lamp poles, high lamp poles, scenic area poles, river poles, mountain top poles, etc. We support processing and customization, and they are widely used in urban management, transportation, energy, landscape, special environments and many other fields.



Product features and advantages

一、 Checkpoint Monitoring Pole

The monitoring pole is a core supporting device in the security monitoring system, and its design combines multiple advantages such as structural strength, functionality and environmental adaptability. The following is a detailed analysis of the advantages and features of its core products:

Structural design and strength advantages

1. Shape and structure: Various shapes and structures such as octagonal pyramid, circle, and square

The octagonal conical design (with a smaller upper diameter and a larger lower diameter) provides a larger support area and lateral stiffness compared to traditional circular or square rods. It can withstand wind force of over 12 (36.9 meters per second) and has a seismic resistance rating of 8, ensuring stability in extreme weather conditions.

1.12 Circular surveillance poles: If the project requires rapid deployment, temporary use, or has high requirements for safe collision and lightweight (such as parking lot barrier poles, mobile security).

1.13 Select square/octagonal surveillance poles: If you are looking for an extremely long service life (over 20 years), high load-bearing capacity and expandability, as well as resistance to extreme weather conditions (such as at highway checkpoints and main roads in smart cities).

1.14 Consideration scenarios: Priority is given to octagonal poles for anti-corrosion and wind resistance in coastal areas. For residential areas and scenic spots, round poles or custom-made antique square poles can be chosen to enhance the aesthetic appeal.

1.15 The actual selection should be based on the budget, equipment load and maintenance cycle - providing in-depth customization services for two types of rod types to meet complex demands.

2. High-strength material

The main rod is made of Q235 low-carbon steel (wall thickness ≥4mm, bottom flange ≥14mm), and the seamless steel pipe process enhances the compressive strength. The cross arm is made of carbon steel pipe (with a wall thickness of 3 to 5mm), taking into account both lightweight and load-bearing requirements.

Precision manufacturing process

Welding technology: Automatic submerged arc welding, with no missed welds or pores in the weld seam, and passed ultrasonic flaw detection inspection (in compliance with GB/T3323-1987 standard). Verticality control: After installation, the verticality deviation is ≤1.0%, ensuring accurate shooting angles of the equipment.

二、Anti-corrosion and durability

2. Multiple surface treatments

2.1 Hot-dip galvanized coating: The zinc coating thickness is ≥86μm (national standard GB/T13912-2002). After acid washing, passivation and other processes, the anti-corrosion life exceeds 30 years.

2.2 Electrostatic powder coating: The surface is covered with a ≥100μm plastic layer (imported plastic powder), with adhesion reaching GB9286-88 grade, strong weather resistance, and color matching is available to adapt to the environment.

2.3 Sealing and anti-seepage design

The top of the pole is sealed and waterproof. The cable passage is optimized to prevent cable cuts. The box body is equipped with a waterproof cabin door, and the protection level reaches IP65.

三、Functions and Safety

3 Integrated equipment box

3.1 The box body is equipped with multi-directional knock holes, supporting the entry of wires up, down, left and right. It is internally equipped with lightning protection grounding devices and leakage/short-circuit protection circuits, meeting electrical safety standards (rated voltage AC220V/380V).

3.2 The box door is connected to the PE point through braided flexible wire to form a continuous protection circuit, preventing the risk of electric shock.

3.3 Flexible Scalability: It can be equipped with multiple devices such as cameras, signal lights, meteorological sensors, and LED screens simultaneously, making it suitable for scenarios like smart transportation, security monitoring, and environmental monitoring.

3.4 Convenient maintenance design: The inspection cabin door adopts a bolt opening type, eliminating the need for special tools during maintenance. The split structure of embedded parts (flange and bolt connection) simplifies transportation and installation.

四、Application Scenarios and Adaptability

4.1 Multi-environment applicability: Harsh climate: For coastal and high-humidity areas, composite material models (such as fiberglass rods) can be selected, which are resistant to salt spray corrosion.

4.2 Complex terrain: The embedded foundation is cast with C25 concrete, and the ground cage structure enhances the uplift resistance, adapting to unstable foundations such as sandy soil and sloping land.

4.3 Wide coverage areas: including urban road monitoring, expressway checkpoints, security checkpoints, water conservancy monitoring, airports and ports, tunnels, Bridges, toll stations, etc. The pole height can be customized from 6 to 12 meters, and the arm length can reach 12 meters.

4.4 Uses: Installing cameras to capture traffic violations, monitor traffic flow, and collect evidence of accidents, etc.

Summary

The octagonal monitoring pole enhances its wind and earthquake resistance through an octagonal conical structure and Q235 high-strength steel. It achieves an extremely long anti-corrosion life with hot-dip galvanizing and electrostatic powder coating. Moreover, it meets the requirements of multi-functional integration and safe operation and maintenance with modular boxes, lightning protection grounding, and intelligent expansion interfaces. Its design takes into account stability, durability and environmental adaptability, making it one of the core infrastructures of modern smart city security systems.

五、Product shape, material and custom specifications

5.1 Product Shape: Circular/Square/hexagonal/octagonal/traffic signal/octagonal monitoring pole

5.2 Product Material: Q235 carbon steel/Aluminum /201 stainless steel /304 stainless steel

5.3 Customizable Specifications

Standard heights or lengths: 1 meter /2 meters /3 meters /4 meters /5 meters /6 meters /6.5 meters /7 meters /8 meters /9 meters /10 meters /12 meters /15 meters /18 meters /20 meters /30 meters, etc

Conventional caliber 30mm/40mm/50mm/60mm/80mm/120mm/140mm/160mm/180mm/200mm/220mm/240mm/260mm/280mm/300mm/320mm/350mm/400mm/450mm/500mm/800mm /1000mm, etc

Conventional thickness: 1.0 mm / 1.2 mm / 1.5 mm / 2.5 mm / 3.0 mm / 4.0 mm / 5.0 mm / 6.0 mm / 8.0 mm / 10 mm / 12 mm, 14 mm / 16 mm, etc

According to the requirements of the buyer, the product price is 60 yuan - 600,000 yuan per set (including hot-dip galvanizing and plastic spraying, with load-bearing standards).
